| Z轴测量范围 | X轴测量范围 | 刀具和探头的最大直径Ø | 刀具和探头的最小直径Ø | 卡规的可测量直径Ø | 刀具最大水平直径Ø | 刀具最小水平直径Ø | 刀具最大垂直直径Ø | 刀具最小垂直直径Ø | 卡规在探头垂直位置的直径Ø | 在探头垂直位置的Z向行程测量损失 | |
| T1非旋转探头 | 600mm/800mm/1000mm | 440mm/540mm*/720mm*250mm/340mm/340mm | 0mm | 100mm/ 50mm/50mm | - | - | - | - | - | - | |
| T1旋转探头： | 600mm/ 800mm/1000mm | 440mm/ 540mm×/720mm* | - | - | - | 280mm/550mm/600mm | 0mm | 690mm | 54mm | 100mm/ 50mm/50mm | 70mm |
| T2旋转探头 | 600mm/800mm/1000mm | 440 mm/540 mm*/720 mm* | - | - | - | 280mm/540mm/720mm | 0mm | 690mm | 50mm | 100mm/50mm/50mm | 75mm |
